Help : OID

Alex Dehaini alexdehaini at gmail.com
Tue Apr 1 15:48:13 CEST 2008


Pallav,
CPU usage - use snmp. This is the OID 1.3.6.1.4.1.9.2.1.57.0

Memory usuage - use  check_snmp_mem.pl from
http://nagios.manubulon.com/snmp_mem.html

System description - snmpwalk the entire device or search for it on cisco
website

Port Status - Which port do you want to monitor. You can use check_tcp or
check_udp

Hope this helps.

Alex


On Tue, Apr 1, 2008 at 12:36 PM, <Pallav.S.Gupta at relianceada.com> wrote:

>
> Dear *Narendran*
>
> I have read the documentation ,the problem is I want to know from where I
> can get the OID for CPU usage,  memory usage , sytem description, port
> status etc
>
>
>
>
>
>
> *<narendran.neelamegam at wipro.com>*
> Sent by: nagios-users-bounces at lists.sourceforge.net
>
> 04/01/2008 05:59 PM
> To
> <Pallav.S.Gupta at relianceada.com>, <misch at multinet.de>cc
> nagios-users at lists.sourceforge.net,
> nagios-users-bounces at lists.sourceforge.net
> Subject
> Re: [Nagios-users] Help : OID
>
>
>
>
> Pallav,
>
> You need to read the documentation...
>
> *http://nagios.sourceforge.net/docs/3_0/quickstart.html*<http://nagios.sourceforge.net/docs/3_0/quickstart.html>
>
> *http://www.nagios.org/docs/* <http://www.nagios.org/docs/>
>
> *http://www.nagioscommunity.org/wiki/*<http://www.nagioscommunity.org/wiki/>
>
> If you face any issues while doing so the group can help you.
>
> Best Regards,
>
> Narendran Neelamegam
> ----------------------------------------------
> Wipro Technologies
> Electronics City, Bangalore
> Mob: +91 9740811699 | Ph: +91 80 3029 6844
> ------------------------------
> *From:* nagios-users-bounces at lists.sourceforge.net [mailto:
> nagios-users-bounces at lists.sourceforge.net] *On Behalf Of *
> Pallav.S.Gupta at relianceada.com*
> Sent:* Tuesday, April 01, 2008 5:34 PM*
> To:* Michael Schwartzkopff*
> Cc:* nagios-users-bounces at lists.sourceforge.net;
> nagios-users at lists.sourceforge.net*
> Subject:* Re: [Nagios-users] Help : OID
>
>
> I want to monitor CPU usage , memory usage , sytem description, port
> status
>
>
>
>
>
> *Michael Schwartzkopff <misch at multinet.de>*
> Sent by: nagios-users-bounces at lists.sourceforge.net
>
> 04/01/2008 05:36 PM
>
> To
> nagios-users at lists.sourceforge.netcc
> Subject
> Re: [Nagios-users] Help : OID
>
>
>
>
>
>
> Am Dienstag, 1. April 2008 13:40 schrieb Pallav.S.Gupta at relianceada.com:
> > Hi All
> >
> > I have installed nagios 3.0 , Now I want nagios to monitor switch rather
> > than monitoring local host.To add the switch I have made changes in
> > switch.cfg file but I am unable to find OID for my switch cisco 3550.
> >
> > I used the command snmpwalk .......... but I started getting a long list
> > of ids , so which ID to chosse from that list.
>
> The OID depends on what you want to look for. So first os all, get
> yourself
> sure, what you want to monitor. CPU load, temperature of the divice,
> package
> or octet throughput (if yes: on what port), ...? When you walked through
> the
> MIB fo your device you will see that the switch delivers a lot of
> information.
>
> --
> Dr. Michael Schwartzkopff
> MultiNET Services GmbH
> Addresse: Bretonischer Ring 7; 85630 Grasbrunn; Germany
> Tel: +49 - 89 - 45 69 11 0
> Fax: +49 - 89 - 45 69 11 21
> mob: +49 - 174 - 343 28 75
>
> mail: misch at multinet.de
> web: www.multinet.de
>
> Sitz der Gesellschaft: 85630 Grasbrunn
> Registergericht: Amtsgericht München HRB 114375
> Geschäftsführer: Günter Jurgeneit, Hubert Martens
>
> ---
>
> PGP Fingerprint: F919 3919 FF12 ED5A 2801 DEA6 AA77 57A4 EDD8 979B
> Skype: misch42
>
> -------------------------------------------------------------------------
> Check out the new SourceForge.net Marketplace.
> It's the best place to buy or sell services for
> just about anything Open Source.
>
> http://ad.doubleclick.net/clk;164216239;13503038;w?http://sf.net/marketplace
> _______________________________________________
> Nagios-users mailing list
> Nagios-users at lists.sourceforge.net
> https://lists.sourceforge.net/lists/listinfo/nagios-users
> ::: Please include Nagios version, plugin version (-v) and OS when
> reporting any issue.
> ::: Messages without supporting info will risk being sent to /dev/null
>
>
>
>
> The information contained in this e-mail message is intended only for the
> use of the individual or entity to which it is addressed. If you are not the
> intended recipient, you should return it to the sender immediately. Please
> note that while we scan all e-mails for viruses we cannot guarantee that any
> e-mail is virus-free and accept no liability for any damage caused by any
> virus transmitted by this email.
> -------------------------------------------------------------------------
> Check out the new SourceForge.net Marketplace.
> It's the best place to buy or sell services for
> just about anything Open Source.
>
> http://ad.doubleclick.net/clk;164216239;13503038;w?http://sf.net/marketplace_______________________________________________
> Nagios-users mailing list
> Nagios-users at lists.sourceforge.net
> https://lists.sourceforge.net/lists/listinfo/nagios-users
> ::: Please include Nagios version, plugin version (-v) and OS when
> reporting any issue.
> ::: Messages without supporting info will risk being sent to /dev/null
>
>
>
>
> The information contained in this e-mail message is intended only for the
> use of the individual or entity to which it is addressed. If you are not the
> intended recipient, you should return it to the sender immediately. Please
> note that while we scan all e-mails for viruses we cannot guarantee that any
> e-mail is virus-free and accept no liability for any damage caused by any
> virus transmitted by this email.
>
> -------------------------------------------------------------------------
> Check out the new SourceForge.net Marketplace.
> It's the best place to buy or sell services for
> just about anything Open Source.
>
> http://ad.doubleclick.net/clk;164216239;13503038;w?http://sf.net/marketplace
> _______________________________________________
> Nagios-users mailing list
> Nagios-users at lists.sourceforge.net
> https://lists.sourceforge.net/lists/listinfo/nagios-users
> ::: Please include Nagios version, plugin version (-v) and OS when
> reporting any issue.
> ::: Messages without supporting info will risk being sent to /dev/null
>



--
Alex Dehaini
Developer
Site - www.alexdehaini.com
Email - alexdehaini at gmail.com
