Xerox WC M24 monitoring

[Tobias Exner]

Hi,

just a little update from me.

I found a good solution to monitoring my Xerox WC M24.

It's little php-snmp plugin from a german company. And it's free for
download.

Here's the link:

nagios-exchange
http://www.nagiosexchange.org/cgi-bin/page.cgi?g=Detailed%2F2664.html;d=1


direct link
http://www.ciphron.de/gfx/pool/check_printer








printer.cfg:

.
.
.
define service{
    use            generic-service    ;
    host_name        xerox24        ;
    service_description    gedruckte Seiten        ;
    check_command        check_printer!public!counter!1    ;
    normal_check_interval    10    ;
    retry_check_interval    1    ;
    }

define service{
    use            generic-service    ;
    host_name        xerox24        ;
    service_description    Toner Black        ;
    check_command        check_printer!public!ink!1    ;
    normal_check_interval    10    ;
    retry_check_interval    1    ;
    }
.
.
.




Cheers,

Tobias




Dan Thagard schrieb:
> I've not worked with the M24, but I use the check_snmp_printer command with the Xerox DocuColor 250 and the Xerox EX700 printers using the 2.43.11.1.1.6.1.x OID range, e.g. "check_snmp_printer!10.0.0.100!public!CONSUM 2.43.11.1.1.6.1.8".
>
> I'm not sure that this is the best (read correct) way, but I can check the consumable status for these printers. If anyone has a better approach I'd love to hear it.
>
> Cheers,
> Dan
>
>
> Dan Thagard
> Director, I.T.
> Gehring Group
> 11505 Fairchild Gardens Ave.
> Suite 202
> Palm Beach Gardens, FL 33410
> P: 561.799.4810
> F: 561.626.6970
> C: 561.632.8833
> E: dan at gehringgroup.com
>
>
> -----Original Message-----
> From: Tobias Exner [mailto:texner at eoipso.com]
> Sent: Sunday, April 19, 2009 3:21 PM
> To: nagios-users at lists.sourceforge.net
> Subject: [Nagios-users] Xerox WC M24 monitoring
>
> Hi list,
>
> is there anybody who know how to monitor a Xerox WorkCenter M24?
>
> There are several plugins available for printers, but none of them seem
> to be build for Xerox.
> Of course I don't tried them all, because I hope there's someone who was
> able to find a solution.
>
>
> Thanks in advance...
>
> Tobias
>
> ------------------------------------------------------------------------------
