status map display as question mark

[Menard, Chris]

Try adding an image to your host (or applicable templates)

I have, this for my sun box template:

        statusmap_image                 sun_server.gd2

and this for M$ boxes:

        statusmap_image         windows_server.gd2

these images are in:

/usr/local/nagios/share/images/logos
From: K Ramanujan [mailto:KRamanujan at JohnDeere.com]
Sent: Thursday, August 27, 2009 3:11 AM
To: nagios-users at lists.sourceforge.net
Subject: [Nagios-users] status map display as question mark


Hi All,


Could some one let me know how to configure status map. I have configure all the host and service definition also


But when I am click on service status the hosts are display as? mark on all side of the map


[cid:image001.jpg at 01CA26F4.2C625D00]


My windows service definition is

define hostextinfo{

hostgroup_name          windows-servers
        notes           This is the Windows server
         icon_image Logo_Windows.gif
        icon_image_alt  WindowsServer SP2
        vrml_image      Logo_Windows.png
        statusmap_image Logo_Windows.gd2
        2d_coords 100,250
        3d_coords 100.0, 50.0,75.0
        }



Need your help here.

Thanks & Regards,
Ramanujan

-------------- next part --------------
An HTML attachment was scrubbed...
URL: <https://www.monitoring-lists.org/archive/users/attachments/20090827/2cdf5a5c/attachment.html>
-------------- next part --------------
A non-text attachment was scrubbed...
Name: image001.jpg
Type: image/jpeg
Size: 11793 bytes
Desc: image001.jpg
URL: <https://www.monitoring-lists.org/archive/users/attachments/20090827/2cdf5a5c/attachment.jpg>
